Specifications
| Model | Indoor Unit | PWFY-P100VM-E-BU |
PWFY-EP100VM-E1-AU (Cooling Mode) |
PWFY-EP100VM-E1-AU (Heating Mode) |
|
| Model | Outdoor Unit | ||||
| Operating mode | Heating | Cooling | Heating | ||
| Capacity | Cooling | kW | 11.2 | ||
| Capacity | Heating | kW | 12.5 | 12.5 | |
| Power Input (Indoor Unit) | Cooling | kW | 0.015 | ||
| Power Input (Indoor Unit) | Heating | kW | 2.48 | 0.015 | |
| Power Input (Outdoor Unit) | Cooling | kW | |||
| Dimension (HxWxD) | Indoor Unit | mm | 800x450x300 | 800x450x300 | 800x450x300 |
| Dimension (HxWxD) | Outdoor Unit | mm | |||
| Power Supply | Indoor Unit | V/Ph/Hz | |||
| Power Supply | Outdoor Unit | V/Ph/Hz | 220-240/1/50 | 220-240/1/50 | 220-240/1/50 |
| Running Current | Indoor Unit | A | |||
| Running Current | Outdoor Unit | A | |||
| Water Temp. | Outlet | ℃ | 30~70 | 30~45 | 10~30 |
| Temp. Range of Heating | Outdoor Condition | °CWB | -20~32 | -20~32 (R2 Serise) / -20~15.5 (Y Serise) | -5~46°CDB (R2 Serise) / -5~46°CDB (Y Serise) |
| Temp. Range of Heating | Inlet Water Temp. | ℃ | 10~70 | 10~40 | 10~35 |
| Circulating Water Operation Volume Range | m³/h | 0.6 ~ 2.15 | 1.8~4.30 | 1.8~4.30 | |
| Connectable Outdoor Unit | City Multi R2 | City Multi R2, YNW | City Multi R2, YNW | ||
| External Static Pressure | Indoor Unit | Pa | |||
| Max. Piping | Length/Height | m | |||
| Refrigerant Pipe Diameter | Gas(Ø) | mm | 15.88 | 15.88 | 15.88 |
| Refrigerant Pipe Diameter | Liquid(Ø) | mm | 9.52 | 9.52 | 9.52 |
| Water Pipe Diameter | Inlet | in. | PT 3/4 Screw | R1 (R3/4 without expansion joint) | R1 (R3/4 without expansion joint) |
| Water Pipe Diameter | Outlet | in. | PT 3/4 Screw | Rc1 (Rc3/4 without expansion joint) | Rc1 (Rc3/4 without expansion joint) |
| Air Volume | Indoor Unit | m³/min | |||
| Noise Level | Indoor Unit | dB(A) | 44 | 29 | 29 |
| Noise Level | Outdoor Unit | dB(A) | |||
| Weight | Indoor Unit | kg | 59 | 33 | 33 |
| Weight | Outdoor Unit | kg | |||
|
|
|
|
| Model | Indoor Unit | PWFY-P100VM-E-BU |
PWFY-EP100VM-E1-AU (Cooling Mode) |
PWFY-EP100VM-E1-AU (Heating Mode) |
|
| Model | Outdoor Unit | ||||
| Operating mode | Heating | Cooling | Heating | ||
| Capacity | Cooling | kW | 11.2 | ||
| Capacity | Heating | kW | 12.5 | 12.5 | |
| Power Input (Indoor Unit) | Cooling | kW | 0.015 | ||
| Power Input (Indoor Unit) | Heating | kW | 2.48 | 0.015 | |
| Power Input (Outdoor Unit) | Cooling | kW | |||
| Dimension (HxWxD) | Indoor Unit | mm | 800x450x300 | 800x450x300 | 800x450x300 |
| Dimension (HxWxD) | Outdoor Unit | mm | |||
| Power Supply | Indoor Unit | V/Ph/Hz | |||
| Power Supply | Outdoor Unit | V/Ph/Hz | 220-240/1/50 | 220-240/1/50 | 220-240/1/50 |
| Running Current | Indoor Unit | A | |||
| Running Current | Outdoor Unit | A | |||
| Water Temp. | Outlet | ℃ | 30~70 | 30~45 | 10~30 |
| Temp. Range of Heating | Outdoor Condition | °CWB | -20~32 | -20~32 (R2 Serise) / -20~15.5 (Y Serise) | -5~46°CDB (R2 Serise) / -5~46°CDB (Y Serise) |
| Temp. Range of Heating | Inlet Water Temp. | ℃ | 10~70 | 10~40 | 10~35 |
| Circulating Water Operation Volume Range | m³/h | 0.6 ~ 2.15 | 1.8~4.30 | 1.8~4.30 | |
| Connectable Outdoor Unit | City Multi R2 | City Multi R2, YNW | City Multi R2, YNW | ||
| External Static Pressure | Indoor Unit | Pa | |||
| Max. Piping | Length/Height | m | |||
| Refrigerant Pipe Diameter | Gas(Ø) | mm | 15.88 | 15.88 | 15.88 |
| Refrigerant Pipe Diameter | Liquid(Ø) | mm | 9.52 | 9.52 | 9.52 |
| Water Pipe Diameter | Inlet | in. | PT 3/4 Screw | R1 (R3/4 without expansion joint) | R1 (R3/4 without expansion joint) |
| Water Pipe Diameter | Outlet | in. | PT 3/4 Screw | Rc1 (Rc3/4 without expansion joint) | Rc1 (Rc3/4 without expansion joint) |
| Air Volume | Indoor Unit | m³/min | |||
| Noise Level | Indoor Unit | dB(A) | 44 | 29 | 29 |
| Noise Level | Outdoor Unit | dB(A) | |||
| Weight | Indoor Unit | kg | 59 | 33 | 33 |
| Weight | Outdoor Unit | kg |
Remarks
There may be some differences between the products’ sizes stated in this page and those of the actual products.
