Horsepower
-
3/4HP
-
1HP
-
1.5HP
-
2HP
-
2.5HP
-
3HP
-
MS-GJ09VA
Split-Type Air-Conditioner
Cooling Type
1HP
Indoor Unit: 295 mm(H) x 798 mm(W) x 232 mm(D)
Outdoor Unit: 429 mm(H) x 662 mm(W) x 257 mm(D)
R410A
Grade 3 Energy Label
Cooling Type
1HP
Indoor Unit: 295 mm(H) x 798 mm(W) x 232 mm(D)
Outdoor Unit: 429 mm(H) x 662 mm(W) x 257 mm(D)
R410A
Grade 3 Energy Label
Share on
Recently Viewed
Feature
More
Easy Clean Design
Nano Platinum Filter
Outdoor unit only 43cm high
Computerized Dehumidification
Powerful Cool
12 Hour Pre-set On/Off
ECONO COOL
I Feel Control
2 years full machine warranty & 5 years compressor warranty
Vertical Auto Swing(7 Modes)
Self Diagnosis
LCD Display Remote Controller
Noise-Reducing Design
Electric Circuit Protection
Auto Re-Start#
#Auto Re-Start function must be set by qualified engineers. Please contact our service centres if you need technical support.
Specifications
| Model | Indoor Unit | MS-GJ09VA | |
| Model | Outdoor Unit | MU-GJ09VA | |
| Color | Indoor Unit | ||
| Operation Mode | Cooling | ||
| Cooling / Heating Capacity | Rated | kW | 2.50 |
| Cooling / Heating Capacity | Rated | BTU/h | 8,530 |
| Cooling / Heating Capacity | Min-Max | kW | - |
| Cooling / Heating Capacity | Min-Max | BTU/h | - |
| Power Consumption | Rated | kW | 0.82 |
| Power Consumption | Min-Max | kW | - |
| Operating Current | A | 3.80 | |
| Air Circulation | m³/min. | 10.70 | |
| C.O.P. | 3.05 | ||
| Dehumidifying Capacity | I/h | 0.80 | |
| Noise Level | Indoor Unit (Si)/Lo-Hi | dB(A) | 25-43 |
| Noise Level | Outdoor Unit | dB(A) | 51 |
| Dimension (H x W x D) | Indoor Unit | mm | 295 x 798 x 232 |
| Dimension (H x W x D) | Outdoor Unit | mm | 429 x 662 x 257 |
| Weight | Indoor Unit | kg | 10 |
| Weight | Outdoor Unit | kg | 24.5 |
| Refrigerant Pipe Diameter | Liquid / Gas | mm | Ø6.35 / Ø9.52 |
| Max. Piping Dimension | Height Difference / Length | m | 10 / 20 |
| Voltage | V | 220 | |
| Phase / Frequency | Single / 50Hz | ||
| Refrigerant | R410A | ||
| Energy Efficiency Grade | 3 | ||
| Optional Parts |
| Model | Indoor Unit | MS-GJ09VA | |
| Model | Outdoor Unit | MU-GJ09VA | |
| Color | Indoor Unit | ||
| Operation Mode | Cooling | ||
| Cooling / Heating Capacity | Rated | kW | 2.50 |
| Cooling / Heating Capacity | Rated | BTU/h | 8,530 |
| Cooling / Heating Capacity | Min-Max | kW | - |
| Cooling / Heating Capacity | Min-Max | BTU/h | - |
| Power Consumption | Rated | kW | 0.82 |
| Power Consumption | Min-Max | kW | - |
| Operating Current | A | 3.80 | |
| Air Circulation | m³/min. | 10.70 | |
| C.O.P. | 3.05 | ||
| Dehumidifying Capacity | I/h | 0.80 | |
| Noise Level | Indoor Unit (Si)/Lo-Hi | dB(A) | 25-43 |
| Noise Level | Outdoor Unit | dB(A) | 51 |
| Dimension (H x W x D) | Indoor Unit | mm | 295 x 798 x 232 |
| Dimension (H x W x D) | Outdoor Unit | mm | 429 x 662 x 257 |
| Weight | Indoor Unit | kg | 10 |
| Weight | Outdoor Unit | kg | 24.5 |
| Refrigerant Pipe Diameter | Liquid / Gas | mm | Ø6.35 / Ø9.52 |
| Max. Piping Dimension | Height Difference / Length | m | 10 / 20 |
| Voltage | V | 220 | |
| Phase / Frequency | Single / 50Hz | ||
| Refrigerant | R410A | ||
| Energy Efficiency Grade | 3 | ||
| Optional Parts |
Remarks
1.The product specifications are provided by factories of Mitsubishi Electric.
2.Before purchase and installation, the space and position needed for installation should be confirmed by qualified engineers.
3.Designs and specifications are subject to change without prior notice.
4.There may be some differences between the products’ sizes stated in this page and those of the actual products.
2.Before purchase and installation, the space and position needed for installation should be confirmed by qualified engineers.
3.Designs and specifications are subject to change without prior notice.
4.There may be some differences between the products’ sizes stated in this page and those of the actual products.
