Water Cooled Compact Cube - MCRV-VNA1
Water Cooled Compact Cube
Share on
Recently Viewed
Feature
More
Less
Specifications
| Model | MCRV-P1750VNA1 | ||
| Capacity Change Mode | |||
| Power Board | MCRV-P1750VNA1-D | ||
| Capacity | Cooling | kW | 175 |
| Capacity | Heating | kW | |
| Power Input | Cooling | kW | 34 |
| Power Input | Heating | kW | |
| COP | Cooling | kW/kW | 5.15 |
| COP | Heating | kW/kW | |
| Dimension | (HxWxD) | mm | 1860 x 1130 x 1350 |
| Power Source | V/Ph/Hz | 380-415V 3-phase 50Hz | |
| Current Input | Cooling | A | |
| Current Input | Heating | A | |
| Circulating Water Volume Range | m³/h | ||
| Water Flow Rate | Chill Water | m³/h | 30.1 |
| Water Flow Rate | Condensing Water | m³/h | 35.9 |
| Temp Range | Cooling | ℃ | |
| Temp Range | Heating | ℃ | |
| Temp Range | Outdoor | ℃ | |
| Temp Range | Chill Water | ℃ | Outlet Temp. : 5-25 |
| Temp Range | Condensing Water | ℃ | Outlet Temp. : 20-45 |
| Diameter of Water Pipe (Standard Piping) | Inlet/Outlet | mm(in) | |
| Diameter of Water Pipe (Inside Header Piping) | Inlet/Outlet | mm(in) | |
| Diameter of water pipe | Chill water side HEX | Inlet | 2 1/2B Housing type joint(by local prepare) |
| Diameter of water pipe | Chill water side HEX | Outlet | 2 1/2B Housing type joint(by local prepare) |
| Diameter of water pipe | Condensing water side HEX | Inlet | 2 1/2B Housing type joint(by local prepare) |
| Diameter of water pipe | Condensing water side HEX | Outlet | 2 1/2B Housing type joint(by local prepare) |
| Net Weight | Standard / Inside Header | kg | 1092 |
|
|
| Model | MCRV-P1750VNA1 | ||
| Capacity Change Mode | |||
| Power Board | MCRV-P1750VNA1-D | ||
| Capacity | Cooling | kW | 175 |
| Capacity | Heating | kW | |
| Power Input | Cooling | kW | 34 |
| Power Input | Heating | kW | |
| COP | Cooling | kW/kW | 5.15 |
| COP | Heating | kW/kW | |
| Dimension | (HxWxD) | mm | 1860 x 1130 x 1350 |
| Power Source | V/Ph/Hz | 380-415V 3-phase 50Hz | |
| Current Input | Cooling | A | |
| Current Input | Heating | A | |
| Circulating Water Volume Range | m³/h | ||
| Water Flow Rate | Chill Water | m³/h | 30.1 |
| Water Flow Rate | Condensing Water | m³/h | 35.9 |
| Temp Range | Cooling | ℃ | |
| Temp Range | Heating | ℃ | |
| Temp Range | Outdoor | ℃ | |
| Temp Range | Chill Water | ℃ | Outlet Temp. : 5-25 |
| Temp Range | Condensing Water | ℃ | Outlet Temp. : 20-45 |
| Diameter of Water Pipe (Standard Piping) | Inlet/Outlet | mm(in) | |
| Diameter of Water Pipe (Inside Header Piping) | Inlet/Outlet | mm(in) | |
| Diameter of water pipe | Chill water side HEX | Inlet | 2 1/2B Housing type joint(by local prepare) |
| Diameter of water pipe | Chill water side HEX | Outlet | 2 1/2B Housing type joint(by local prepare) |
| Diameter of water pipe | Condensing water side HEX | Inlet | 2 1/2B Housing type joint(by local prepare) |
| Diameter of water pipe | Condensing water side HEX | Outlet | 2 1/2B Housing type joint(by local prepare) |
| Net Weight | Standard / Inside Header | kg | 1092 |
Remarks
Cooling/ Heating capacity is based on following condition:
Standard cooling capacity: Outdoor 35°C DB/19°C WB; outlet water temp 7°C, inlet water temp 12°C
Standard heating capacity: Outdoor 7°C DB/6°C WB; outlet water temp 45°C, inlet water temp 40°C
Standard cooling capacity: Outdoor 35°C DB/19°C WB; outlet water temp 7°C, inlet water temp 12°C
Standard heating capacity: Outdoor 7°C DB/6°C WB; outlet water temp 45°C, inlet water temp 40°C
